The brake system is considered one of the main components of safety for any vehicle. On the rear axle of many cars, there are drum mechanisms that need attention from time to time. Most often, owners have to remove the drum to replace the brake shoes or check the condition of the components. Let's take a detailed look at how to remove the brake drum, and what to do if it is stuck and does not want to come off.

In what cases is drum removal required

The need to remove the drum arises in a number of situations:
  • to install new brake shoes;
  • to inspect the wheel cylinders and spring mechanism;
  • when extraneous noises occur during braking;
  • to clean parts and apply lubricant.

Procedure for removing the drum

Removing the drum cannot be called a complicated operation, but haste and carelessness are inappropriate here.
  1. Place the car on a level surface and put wheel chocks under the wheels.
  2. Jack up the required wheel and remove it.
  3. Inspect the drum: it often has threaded holes. By screwing bolts into them, you can easily move the part from its place.
  4. If there are no such holes, lightly tap the drum with a rubber mallet around the circumference, turning it.
  5. Then pull the drum towards you and remove it.

What to do if the drum is stuck

Quite often, the drum "seizes" to the hub due to corrosion or wear. In such a situation, it is important to understand how to remove a stuck brake drum. You can try the following techniques:
  • treat the joint with a penetrating fluid like WD-40;
  • tap the side surface of the drum with a rubber or copper mallet;
  • use bolts in the technological holes, if any;
  • slightly recess the shoes by loosening the adjustment through a special window in the shield.
The main rule is not to apply excessive force, otherwise you can damage the hub or the shoes.

Features of removing the drum on a VAZ 2107

Owners of the "classic" will find it useful to know how to remove the brake drum on a VAZ 2107.
  1. First, loosen the parking brake cable so that the shoes do not create obstacles.
  2. Remove the wheel.
  3. If the drum does not give in, use the bolts from the threaded holes.
  4. If it is severely stuck, apply lubricant and carefully tap with a mallet.
  5. After removing the drum, inspect all parts of the brake assembly.

Removing the rear drum on a VAZ 2106

The brake design of the VAZ 2106 is almost the same. To understand how to remove the rear brake drum on a VAZ 2106, proceed similarly: release the handbrake, remove the wheel, and carefully slide the drum off. If necessary, bolts or penetrating fluid will help.

How to remove the drum on a Daewoo Lanos

Many drivers are interested in how to remove the rear brake drum on a Lanos. On the Daewoo Lanos, the process is largely similar:
  1. Remove the wheel.
  2. Loosen the handbrake cable to make the drum easier to remove.
  3. If it is stuck, use penetrating lubricant and bolts in the threaded holes.
  4. Tap with a mallet around the circumference to avoid misalignment.
As you can see, how to remove the brake drum on a Lanos is not a difficult question, although it requires some patience.

Useful recommendations and safety measures

  • Be sure to secure the car with a jack and additional supports.
  • Do not apply rough force when removing.
  • Before reinstalling, clean the seating surface and lubricate it to avoid sticking in the future.
  • After assembly, check the operation of the brakes by starting to move at a low speed.

Conclusion

Now you know how to remove the rear brake drum on cars such as the VAZ 2106, VAZ 2107, or Daewoo Lanos. We have reviewed how to remove a stuck brake drum, as well as what safety measures will help you do the job safely. If the drum is severely stuck and does not give in even after treatment with lubricant, it is wiser to contact a car service to avoid damaging the brake system components.
