Windshield washer is an important system that provides the driver with a good view and safety on the road. If the pump stops working, fluid is not supplied to the glass, and driving in bad weather becomes a problem. Many Geely CK owners face the question: how to remove the Geely CK washer pump and replace it with your own hands? In this article, we will analyze the dismantling process step by step, so that even a novice car enthusiast can handle the task.

The windshield washer system is a key element responsible for a clear view and, consequently, driving safety. When the pump fails, fluid delivery to the windshield stops, creating serious inconvenience in bad weather. Owners of Geely CK often wonder: how to remove the washer pump on a Geely CK and replace it yourself? This material details, step by step, the removal process that even a beginner can handle.

Why the washer pump fails

Before starting disassembly, it is important to understand why the pump needs to be removed. In the Geely CK model, failure of this component can be caused by several factors:

Contamination of the filter element or nozzles. Debris entering the reservoir creates excessive load on the pump.
Electric motor malfunction. The device stops pumping fluid.
Wiring damage or loose contacts. The electrical part of the car wears out over time.
Freezing of the working fluid. If water was poured instead of winter washer fluid, the mechanism may jam.

If diagnostics show that the pump is at fault, it must be removed and replaced.

Preparatory measures

To remove the pump from the reservoir, a minimal set of tools is required:

flathead screwdriver;
pliers;
protective gloves;
container for draining remaining fluid.

It is better to carry out the work in a garage or on a flat area, always securing the car with the parking brake.

Step-by-step process of removing the Geely CK washer pump

Disconnect power.
To avoid a short circuit, disconnect the negative battery terminal.
Locate the washer reservoir.
In the Geely CK, it is located in the engine compartment, near the front bumper.
Empty the reservoir.
To prevent washer fluid from getting onto the engine, drain the remaining fluid into a prepared container.
Disconnect the electrical connector.
Carefully detach the wiring harness from the pump.
Disconnect the hose.
Using pliers, carefully remove the rubber hose through which fluid flows to the nozzles.
Remove the pump.
The device is installed in the reservoir through a rubber sealing ring. To remove the pump from the washer reservoir, gently pry it with a screwdriver and pull it toward you. It should come out without excessive force.
Inspect the seal.
If the rubber gasket is damaged, it is better to replace it with a new one immediately, otherwise leaks may occur.
Install the new pump.
Proceed in reverse order: place it into the reservoir opening, reattach the hose, and connect the electrical connector.

Replacement recommendations

Purchase only original parts or proven analogs compatible with the Geely CK.
Do not allow the pump to run dry — without fluid in the reservoir, it may burn out.
After completing assembly, be sure to test the system: fill the fluid and activate the washer from the cabin.
If the pump does not work, the likely cause is in the wiring or a blown fuse.

Conclusion

Now you know how to remove the Geely CK washer pump yourself. This procedure requires no special skills and takes no more than half an hour. The key is to act carefully to avoid damaging plastic elements and seals. Thus, replacing the washer pump on a Geely CK is a simple operation that allows you to quickly restore system functionality and ensure safety in any weather conditions.
